اکسس پوینت بی سیم و OutDoor تی پی لینک TP-Link CPE610 از فناوری TP-Link Pharos MAXtream TDMA بهره برده کمه باعث بهبود توان عملیاتی ، ظرفیت و تأخیر می شود و دارای محفظه مقاوم در برابر آب و هوا با استاندارد IP65 همراه با ۱۵ کیلوولت ESD و ۶ کیلوولت محافظت در برابر صاعقه مناسب بودن در تمام شرایط آب و هوایی را تضمین می کند. CPE610 دارای حافظه رم ۶۴MB DDR2 RAM,8MB و پردازنده Qualcomm 560MHz CPU, MIPS 74Kc می باشد و به نرم افزار مدیریت متمرکز Pharos Control مجهز است و به کاربران کمک می کند تا به راحتی همه دستگاه های شبکه خود را از طریق یک رایانه مدیریت کنند
بازگشت به محصولات
TP-LINK WBS510 5GHz 300Mbps Outdoor Wireless Base Station
تومان۲,۸۰۸,۰۰۰ – تومان۳,۰۲۴,۰۰۰
اکسس پوینت بیسیم 300Mbps تی پی لینک مدل CPE610
تومان۴,۴۵۰,۰۰۰ – تومان۴,۵۹۹,۰۰۰
قدرت گیرندگی آنتن : ۲۳ دسی بل
تعداد آنتن : یک عدد
گواهینامه ها : CE, FCC, RoHS, IP۶۵
شناسه محصول:
CPE610
دسته: اکسس پوینت تی پی لینک, روتر و اکسس پوینت
توضیحات
نظرات (0)
اولین کسی باشید که دیدگاهی می نویسد “اکسس پوینت بیسیم 300Mbps تی پی لینک مدل CPE610”
برای فرستادن دیدگاه، باید وارد شده باشید.
مشخصات فنی
HARDWARE FEATURES | |
---|---|
Processor | 560MHz CPU, MIPS 74Kc |
Memory | 64MB DDR2 RAM,8MB Flash |
Interface | 1 10/100Mbps Shielded Ethernet Port (LAN/POE) 1 Reset Button |
Power Supply | Passive Power over Ethernet via LAN (+4,5pins; -7,8pins) Voltage range: 16-27VDC |
Power Consumption | 8.8 W Note: When deployed using Passive PoE, the power drawn from the power source will be higher by some amount depending on the length of the connecting cable. |
Dimensions ( W x D x H ) | 14.4 x 11.0 x 8.1 in |
Antenna Gain | 23dBi |
Antenna Beamwidth | 9°(Azimuth), 7°(Elevation) |
Protection | 15KV ESD Protection 6KV Lightning Protection |
Enclosure | Material: Outdoor PC stabilized plastic Weatherproof: IP65 water and dust proof design |
WIRELESS FEATURES | |
---|---|
Wireless Standards | IEEE 802.11a/n |
Proprietary Protocol | TDMA Mode (with Pharos MAXtream enabled) |
Wireless Speeds | Up to 300Mbps (40MHz,Dynamic) Up to 144.4Mbps (20MHz,Dynamic) Up to 72.2Mbps (10MHz,Dynamic) Up to 36.1Mbps (5MHz,Dynamic) |
Frequency | 5.15~5.85GHz |
Transmit Power | Max. 25dBm (Adjustable power by 1dBm) |
SOFTWARE FEATURES | |
---|---|
Network Configuration | WAN: Static/Dynamic/PPPoE/L2TP/PPTP LAN: Static/Dynamic/DHCP Forwarding: ALG/UPnP/Virtual Server/Port Trigger Security: SPI Firewall/ Ping Forbidden/DoS Protection Access Control Static Routing Bandwidth Control IP & MAC Binding |
Wireless Configurations | Pharos MAXtream TDMA Technology Selectable Channel Width: 5/10/20/40MHz Auto Channel Selection Transmit Power Control Dynamic Frequency Selection(DFS) WDS Enable/Disable Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption, 64/128/152-bit WEP Encryption SSID Broadcast Enable/Disable Multi-SSID with VLAN Tagging(AP Mode only) Distance/ACK Timeout Setting Wireless MAC Address Filter Wireless Advanced: Beacon Interval/RTS Threshold/Fragmentation Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia |
Management | Discovery and Remote Management via Pharos Control application HTTP/HTTPS Web-based management System log SNMP Agent(v2c) Ping Watch Dog Dynamic DDNS SSH Server |
System Tools | Indicators:Signal Strength/Noise/Transmit CCQ/CPU/Memory Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP Spectrum Analyzer Speed Test Ping Traceroute |
System-level Optimizations | Optimized IGMP Snooping/Proxy for multicast applications Hardware watch dog |
POE ADAPTER FEATURES | |
---|---|
Dimensions(W x D x H) | 4.3 x 2.2 x 1.3 in |
Interfaces | 1 AC Jack with Earth Ground 1 10/100Mbps Shielded Ethernet Port (Power + Data) 1 10/100Mbps Shielded Ethernet Port (Data) |
Button | Remote Reset Button |
Power Status LEDs | Green |
Input | 100-240VAC, 50/60Hz |
Output | 24VDC, 0.5A Max +4, 5pins; -7, 8pins. (Support up to 60m Power over Ethernet) |
Efficiency | >84.29% |
Certifications | CE/FCC |
OTHERS | |
---|---|
Certification | FCC, RoHS |
Package Contents | Outdoor Wireless CPE 24V 0.5A Passive PoE Adapter Pole Mounting Straps AC Power Cord Installation Guide |
Environment | Operating Temperature: -40℃~70℃ (-40℉~158℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~95% non-condensing |
