Cisco SF110D-16 16-Port 10/100 Desktop Switch

Specifications Description
Standards
IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet, IEEE 802.3ab 1000BASE-T Gigabit Ethernet,
IEEE 802.3z Gigabit Ethernet, IEEE 802.3x Flow Control, 802.1p priority, Energy Efficient Ethernet, 802.3af, Power over
Ethernet
Cabling type Category 5e or better
LED indicators
System/PWR, link/activity, 100M,

*Max PoE, cable diagnostics, loop detection, gigabit,
* mini-GBIC
*
*
if present
Physical Interfaces
Ports 10/100/1000 Ethernet, with support for 802.3af PoE, power port for AC adapter or power cord
Power supply DC 12V, 1.0A
Lock slot Slot for Kensington lock
Physical Specifications
Physical dimensions (W x D x H) 6.30 x 3.54 x 1.73 inches (160 x 90 x 44 mm)
Ports 16 RJ-45 connectors for 10BASE-T/100BASE-TX
Fan/fanless models All models have no fans and are fanless, except for SG100-24HP
Performance
Switching capacity 3.2 Gbps
Forwarding capacity 1.4 mpps
Capabilities
Head-of-line (HOL) blocking HOL blocking prevention
Jumbo frame 9216 bytes
Quality of service (QoS) 802.1p priority based, 4 hardware queues, priority queuing and Weighted Round-Robin (WRR)
Loop detection Helps discover loops in the network to avoid broadcast storms
Cable diagnostics Quickly identify and troubleshoot network cable faults and/or shorts
Mounting and Physical Security
Mounting options Desktop or rack mount
Physical security lock Kensington lock slot
Environmental
200+
Countries we Sold
18,000+
Customers Trusted
$20,000,000
Inventory Available
50%-98%
Off Global List Price
100%
Safe Online Shopping
Compliance/
certifications
UL (UL 60950), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A, FCC Class B
*
*select models
Operating temperature 32° to 104°F (0° to 40°C)
Storage temperature -4° to 158°F (-20° to 70°C)
Operating humidity 10% to 90%, relative, noncondensing
Storage humidity 5% to 90%, relative, noncondensing
Package Contents
● Cisco 110 Series switch
● Power cord/power adapter
● Quick-start guide
● Mounting hardware
