D-Link DGS-1024A 24-Port Unmanaged Gigabit Switch

Number of Ports
• Twenty-four 10/100/1000 Gigabit ports

Standards
• IEEE 802.3 10BASE-T Ethernet
• IEEE 802.3u 100BASE-TX Fast Ethernet
• IEEE 802.3ab 1000BASE-T Gigabit Ethernet
• ANSI/IEEE 802.3 NWay auto-negotiation
• IEEE 802.3x Flow Control

Data Transfer Rates
Ethernet:
• 10Mbps (half duplex)
• 20Mbps (full duplex)
Fast Ethernet:
• 100Mbps (half duplex)
• 200Mbps (full duplex)
Gigabit Ethernet:
• 2000Mbps (full duplex)

Network Cables
10BASE-T:
• UTP CAT 3, 4, 5/5e (100m max)
• EIA/TIA-586 100-ohm STP (100m max)
100BASE-TX, 1000BASE-T:
• UTP CAT 5/5e (100 m max)
• EIA/TIA-568 100-ohm STP (100m max)

Functionality
D-Link Green Features
• IEEE 802.3az Energy Efficient Ethernet (EEE)
• Link status detection power saving
• Cable length detection power saving
• RoHS Compliance

LAN Features
• Back pressure at half-duplex operation
• Auto MDI/MDIX
• Wire speed reception and transmission
• Store-and-Forward switching method
• 16K MAC addresses
• 3.5Mbits RAM for data buffering
• Jumbo Frames: 9216 Bytes
• Switching Capacity 48Gbps

Port Packet Filtering
• 10M: 14,880pps
• 100M: 148,800pps
• 1000M: 1,488,000pps

LEDs
• Power LED
• 24 Link/Activity/Speed LEDs (one per port)

Power Inputs
• Switching 12V/1.5A Level V power adapter

Power Consumption
• Power On (Standby): AC input: 6.86 watts
• Power Max.: AC input: 14.17 watts

Heat Dissipation
• Power On (Standby): AC input: 23.41BTU/h
• Power Max.: AC input: 48.35BTU/h

MTBF
• 401,516 hours

Dimensions
• 257 x 178 x 46mm

Weight
• 0.76kg

Operating Temperature
• 0 to 40°C

Storage Temperature
• -10 to 70°C

Humidity
• 5% to 90% non-condensing

Certifications
• FCC Class A
• ICES-003 Class A
• CE Class A
• VCCI Class A
• C-Tick Class A
• uCL
• CB
